The Serveredge basic PDUs are the most efficient way to power protect your rack mount equipments. Serveredge PDUs are built to both Australian & International standards and requirements, so that your equipment can deliver the most optimum performance while using minimum of your valuable rack space. The PDUs have a Metal Alloy casing which makes them durable for rack mount use and also allows both vertical and horizontal applications.
PRODUCT FEATURES
• Output Ports: (12) 3 Pin AUS GPO
• Overload Protection
• Horizontal Mounting capabilities saves valuable rack space.
• Optional 100mm recessed brackets included
• Input Power Source: 3 Pin Captive Plug, 32A
* Warranty: 2 Years Manufacturers Warranty
PRODUCT SPECIFICATIONS
| Configuration | 2RU, Horizontal |
| Colour | Black |
| Maximum Depth | 45mm |
| Maximum Height | 90mm |
| Maximum Width | 482.6mm |
Output |
|
| Output | 12 x 3 Pin AUS GPO |
Input |
|
| Input | 1 x 3-Pin Round Captive Plug |
| Cable-length | 2m |
| Maximum input current | 32A |
| Voltage | 240V |
Conformance and Compliance |
|
| EESS Conformity |
PACKAGING INCLUDES
| SEDG-12P-GPO-32A | 1 |
YOU'RE REVIEWING:
12 Port 2RU Basic PDU, (12) 3 Pin AUS GPO Output (1) 3 Pin captive Plug Input, 32A, 240V W/ Overload Protection
