Designed for when performance, reliability and value count, Elements series cables are budget friendly while providing professional performance for home or commercial use.
Engineered with low profile connectors and high flexibility, low bend radius cable, these cables are ideal for use where space is limited such as behind displays and in equipment racks.
Premium Performance
Go beyond the 60Hz barrier. Elements Series DisplayPort cables allow high refresh rates on monitors which support it for silky smooth, lag free video. They are ideal to get the most out of your gaming set up.
Reliability You Can Count On
Engineered with professional applications in mind, these cables utilise highly flexible 30AWG (up to 3m) and 28AWG (5m+) cable for reliable performance and ease of installation in home or business uses.
Years of feedback about other companies’ DisplayPort cables failing in the field has led us to develop our own unique connector construction to ensure long lasting reliability.
Our robust ABS low profile connectors provide a comfortable grip and easy insertion while standing up to use in high traffic environments. The connectors are latching, meaning they can’t fall out once connected.
With hundreds of thousands of our cables installed in professional environments, this range draws upon our vast experience of providing products that last the test of time in the most demanding applications.
Whether at home or in the office, you can be assured that these cables won’t let you down.
PRODUCT FEATURE
- Connects DisplayPort source equipment to DisplayPort displays and other equipment
- DisplayPort 1.2 / 4K compatible
- Supports 3D video and Ultra HD/4K resolutions at 60Hz
- Highly flexible cable with low bend radius can be used in tight spaces in equipment racks, AV furniture and behind wall mounted displays
- Robust ABS low profile connectors provide a comfortable grip and easy insertion while standing up to use in high traffic environments
- Latching connectors to ensure secure connection
- Data rates up to 21.6Gbps. Refresh rates up to 240Hz at 1080p.
PRODUCT SPECIFICATION
Input / Output
DisplayPort Male <-> DisplayPort Male (bidirectional)
Resolution
Supports up to 4K/UHD 4096x2160 at 60Hz
Full HD 1920x1080 at up to 240Hz
Video Support
- Supports 3D video
- Refresh rates up to 240Hz at 1080p
- Adaptive Sync / FreeSync compatible
Data Rate DisplayPort 1.2 HBR2/21.6Gbps class cable
(Backwards compatible with all previous DisplayPort standards)
Physical Characteristics
Materials: PVC Jacket, ABS Connector | Colour: Dark Grey
Warranty
Lifetime
Compliance
RoHS
AVAILABLE LENGTHS
| Part No. |
Length |
| ELDHD-01 | 1m |
| ELDHD-02 | 2m |
| ELDHD-03 | 3m |
| ELDHD-05 | 5m |
